High definition: 8.3 million effective pixels, 1/2.8-inch CMOS sensor
Multiple signal formats: 1080p60/50/30/25 and other resolution formats
Ultra wide viewing angle: 108 degree horizontal field of view
Ultra long focal length: 4x optical zoom
Rich and comprehensive interfaces: HDMI/USB3.0/IP simultaneous output
Product details
| model |
ST3200UK-04 |
| Imaging devices |
1/2.8 inch 8.3 million effective pixel CMOS |
| Optical zoom |
4 times |
| Horizontal field of view angle |
108°(w)~32°(T) |
| Minimum illuminance |
0.5lux |
| resolving power |
1920×1080p60/50The1920×1080p30/25etc. |
| Wide dynamic range |
support |
| Video output |
HDMl、USB3.0、IP |
| Control interface (method) |
IP、RS-232、 infrared remote control |
| control protocol |
VlSCA、PELCO-D/P、ONVIF、VISCA over IP |
| Video compression format |
H.264、H.265 |
| level/Vertical rotation range |
-175°～ 175°/-30°～ 90° |
| Pre-set position |
100 of them |
| power supply |
DC 12V/1.3A (maximum) |
| body color/Size/Weight |
silver gray/142×125×157mm/1.5Kg |
