Audio and video all-in-one machine
  • Audio and video all-in-one machine
GD3200UAI-4K

4K Ultra High Definition: Equipped with a 1/2.8 inch high-quality 4K CMOS sensor, it supports 4K ultra high definition and can provide up to 4K image output, presenting clear and realistic ultra high definition videos, vividly showcasing the expressions and actions of characters; Simultaneously compatible with resolutions such as 1080P and 720P;

Built in microphone: Built in MIC microphone, 360 ° omnidirectional pickup, unique noise suppression algorithm, allowing your voice to be perfectly presented, with an effective pickup distance of up to 3.5 meters;

Wide angle undistorted lens: 90 ° wide angle undistorted lens;

AI humanoid tracking: supports automatic humanoid tracking, automatically zooming in and out of characters to form the best exit image; When AI is turned off, the lens automatically adjusts to 60 °, and when AI is turned on, the lens can automatically adjust to 90 °. (No Ai in 4K mode, 2K and 1080pft e Ai)

Video output interface: video output interface type-C&type-A;

Multiple audio and video compression standards: supports YUY2, MJPG, H264 video compression;

Low noise and high signal-to-noise ratio: Low noise CMOS effectively ensures ultra-high signal-to-noise ratio of camera videos, even in ultra-low light conditions, maintaining a clean and clear image;

Diversified installation: Free selection of installation positioning, the device comes with a folding stand, which can be easily installed above LCD screens, computer displays, desktop placement, or tripod installation, making installation convenient and reliable;

Easy to use: No need to download drivers, plug and play, with a convenient and concise user experience; One cable meets the needs of a camera, microphone, and speaker in one.

Multiple application scenarios: personal video applications, video conferencing, collaborative work, etc;

Product details

technical parameter

parameter/Model number

camera lens

Camera and lens parameters

image sensor

1/2.8-inch high-quality 4K CMOS sensor

Image scale

16:9

Video output interface

1-channel Type-C&Type-A interface:

Audio input

built-inMIC microphone microphone

video signal

4k, 2K, 1080P, 720P, 480P. 360P

visual angle

90°

focal length

f=2.1mm

aperture

F2.9

Minimum illuminance

0.1Lux(F1.8, AGC ON)

focusing

automatic

white balance

automatic

exposure

automatic

Backlight compensation

automatic

Signal to noise ratio

≥50dB


USB Features

Supporting operating systems

Windows 7 (only supports 1080p and below), Windows 8.1, Windows 10; macOS 10.10 or higher; Linux (requires support for UVC); Android

Video compression format

NV12、MJPG、H264

USB audio

support

USB communication protocol

UVC、UAC

hardware requirements

2.4 GHz Intel @ Core 2 Duo processor or higher, 2GB memory or higher, type-C


Other parameters

Working voltage and current

Voltage

5V

electric current

500mA(Min)

power waste

5W(max)

Storage temperature

-40℃~60℃

Storage humidity

20%~90%

working temperature

-10℃~40℃

Working humidity

20%~80%

Size (length)X width X height)

800mm*52mm*60mm

weight

about228g

Usage environment

indoor

Random attachments

1.5m Type-C Type-A Adapter, Instruction Manual, Certificate of Conformity
