Product details

Functional features:

The equipment complies with the international standard IEC 60065

● Metal panel, metal square pole design

● Adopting a highly sensitive and dynamic 14mm gold-plated capacitive pickup head

● Support switching between conference host related modes

● Support any microphone configuration as the chairman

The chairman unit and representative unit can be set arbitrarily

● Support one click mode conversion (in Chairman mode)

Adopting three damping zero pressure shaft technology to achieve stable and reliable support for the shaft, supporting more than 30000 non-destructive rotations

● High damping elastic suspension type sound head mounting bracket, effectively reducing desktop vibration and friction noise transmission of microphone tubes, etc

● Binding role ID

Effective pickup distance of 80cm or more

● Support hot swappable data recovery

● Press the button to turn on the light

Technical parameters:

● Radio head: Polarized capacitor sound head

● Directionality: Supercardiform

Frequency response: 20Hz~20000Hz

Signal to noise ratio: 74 dB, 1 kHz at 1 Pa

● Upper limit of input sound pressure: 128 dB SPL, 1 kHz at 1% T.H.D

Dynamic range: 106 dB, 1 kHz at Max SPL

Total harmonic distortion:<0.05%

Sensitivity: -42dB

Impedance: 100 ohms

Working voltage: 24V DC ± 5%

Working current: 80mA ± 5%

● Connection method: junction box, T-head, handle

● Connector: Large 6-core

Tail line length: 70cm

● Unit opening quantity: 1-8 optional

● Numbering function: Supports automatic and manual numbering

● Installation method: desktop style
